2025 Inductive Full-Bright Two-Wire PLC Controller
$25.00
Stair Light Control System
What’s in the box?
1pc LED Power-free Controller
2pcs PIR Sensor
Please note the dedicated main wire is required to purchase from our factory based on the actural number of steps to match this PLC controller.
Product Specifications
| Model Number | PLC QL-V1 |
|---|---|
| Input Voltage | AC 180-260V |
| Total Power | 500W |
| Stair Step Power Consumption | 24W |
| Maximum Number of Steps | |
| Product Size | 140mm*63mm*24mm |
| Output Voltage | DC 24W |
| Certification | CE |
| Length of Running Light | |
| Sensors | 2 (DC-5V) |
| Batteries Included | No Need |
You must be logged in to post a review.
Free Shipping
Carrier: EMS
Cost: Free
Process Time 2-10 Working days
Shipping Time 2-5 weeks
